HKS DOWNPIPE per HONDA CIVIC TYPE-R FK8

Front pipe increased to 3 inches.
Catless downpipe.
Improves power delivery and throttle response.

■Concept

The K20C engine was designed for use in a normal road car and features a catalytic converter, removing this converter eliminates its restricting effects which significantly increases the engine horsepower.
HKS developed an extension pipe without the catalytic converter and a frontpipe that will connect it to a catback exhaust system.

■Features

• Removing catalytic converter results in a more linear boost and throttle response.
• Uses 3 inch pipes, compatible with HKS catback exhausts.
• A perfect addition to intake, intercooler and other HKS products for future ECU tuning and boostup.
• Decreases secondary exhaust gas pressure from turbine and reduces exhaust restriction.

Max Power
HKS (100 Octane)	383HP / 6500rpm
HKS (91 Octane)	349HP / 630rpm
Stcok (91 Octane)	300HP / 6000rpm
Max Torque
HKS (100 Octane)	376Ft-Lbs / 6500rpm
HKS (91 Octane)	360Ft-Lbs / 6300rpm
Stcok (91 Octane)	295Ft-Lbs / 4400rpm

Vehicle	Model	Engine	Model Year	Code No.	Manual	Remarks
CIVIC TYPE R	FK8	K20C	17/09 -22/08	33006-KH001
