Assetto Regolabile D2 Rally Asphalt Coilover per Toyota Supra A90 (2019+)

D2 Asphalt Rally Coilovers
Suitable for fast driving on degraded road surfaces
For Toyota Supra MK5 (2019+)
36-stage damping adjustable
Independent ride height and spring preload adjustment
Flawless damping, even under small strokes
OEM brake hoses brackets
Corrosion resistant aluminium construction
1 year manufacturer warranty
TÜV and ISO-9001 approved

Coilover or Inboard Springs ?

This model of adjustable suspension offers you the choice between inboard springs (OEM style set-up), or coilover springs (spring around the shock absorber). Generally lighter and easier to adjust, coilover springs are recommended for tuned vehicles, equipped with a roll cage or used in motorsport. For a standard vehicle used on the open road, D2 recommends keeping the inboard springs setup. Note that between a coilover assembly or a separate assembly, the spring rates can be different : this is a difference in technical design due to the shape of the springs, the design of the vehicle's axles, or even the position of the original springs on the chassis. In feel and use, the separate and coilover models are identical, and show no significant difference in driving performance or comfort.

D2 Asphalt Rally Coilovers Specifications

The D2 Asphalt Rally series is particularly suitable for poor and degraded road surfaces, found during road rallying. Thanks to their superior oil capacity and large piston diameter (44 mm), these dampers guarantee flawless operation and consistent damping, even under small strokes. Their wide range of adjustment allows for a precise tuning and suspension setup, while giving full damper control regardless of ride height (independent height and preload adjustment). Front camber can be adjusted via the top mounts (McPherson struts only).

Using monotube dampers, D2 Racing coilovers offer a lowering range of up to 10-12 cm (depending on the model), while being corrosion resistant thanks to their aluminium construction. Damping is 36-stage adjustable, providing a soft or firm ride, whichever is required. Often lighter than OEM units, D2 coilovers also help reduce weight.

All D2 products are TÜV and ISO-9001 approved and benefit from a one-year manufacturer warranty. For your specific needs, it is possible to modify spring rates; D2 France always keeps a large choice of spare parts in stock, to facilitate maintenance and repair of your suspensions, without delaying other projects. Please contact us for more information. Note : these coilovers aredesigned for asphalt rally and fast road use. D2 manufactures a specific range for a other surfaces, such as gravel or snow.

Characteristics

Car Make
Toyota

Car Model
Toyota Supra

Car Version
Toyota Supra MK5 (2019+)

Chassis Code(s) / Type
J29, A90

Range
D2 Rally Asphalt

Front Top Mounts
Pillowball, camber adjustable

Rear Top Mounts
Pillowball (non adjustable)

Front Springs
16 kgF/mm

Rear Springs
14 kgF/mm
