D2 Sports Coilovers
Versatile suspension for road and track
For BMW M235i F22 (2014+)
36-stage damping adjustable
Independent ride height and spring preload adjustment
OEM brake hoses brackets
Corrosion resistant aluminium construction
1 year manufacturer warranty
TÜV and ISO-9001 approved
Coilover or Inboard Springs ?
This model of adjustable suspension offers you the choice between inboard springs (OEM style set-up), or coilover springs (spring around the shock absorber). Generally lighter and easier to adjust, coilover springs are recommended for tuned vehicles, equipped with a roll cage or used in motorsport. For a standard vehicle used on the open road, D2 recommends keeping the inboard springs setup. Note that between a coilover assembly or a separate assembly, the spring rates can be different : this is a difference in technical design due to the shape of the springs, the design of the vehicle's axles, or even the position of the original springs on the chassis. In feel and use, the separate and coilover models are identical, and show no significant difference in driving performance or comfort.
D2 Sport Coilovers Specifications
Designed for sports driving enthusiasts on the road and on the track, the D2 Sport series is versatile and of very high quality. Rated around 30% stiffer than the Street series (hydraulics and springs), they provide superior performance by slightly sacrificing comfort. These suspensions are ideal for mixed use on road and track, and have large adjustment possibilities : height and spring preload are adjusted independently, maintaining full damper stroke and optimal comfort regardless of ride height. Front camber can be adjusted via the top mounts (McPherson struts only).
Using monotube dampers, D2 Racing coilovers offer a lowering range of up to 10-12 cm (depending on the model), while being corrosion resistant thanks to their aluminium construction. Damping is 36-stage adjustable, providing a soft or firm ride, whichever is required. Often lighter than OEM units, D2 coilovers also help reduce weight.
All D2 products are TÜV and ISO-9001 approved and benefit from a one-year manufacturer warranty. For your specific needs, it is possible to modify spring rates; D2 France always keeps a large choice of spare parts in stock, to facilitate maintenance and repair of your suspensions, without delaying other projects. Please contact us for more information.
Characteristics
Car Make
BMW
Car Model
BMW 2 Series F22 / F23 (2014+)
Car Version
BMW M235i F22 (2014+)
Chassis Code(s) / Type
F22
Range
D2 Sport
Front Top Mounts
Pillowball, camber adjustable
Rear Top Mounts
Pillowball (coilover springs setup) or without mounts (inboard springs setup)
Front Springs
10.5 kgF/mm
Rear Springs
12~14 kgF/mm
